Portable Stereotaxic Instrument for Mouse

The RWD portable stereotax for mouse includes 3 axes, a left mouse arm, a mouse nose clip, 18° and 45° mouse ear bars, and a standard probe holder. Other assemblies such as dual manipulator, digital stereotax, etc. are also available.

Overview
Specifications
References
Links

The U-frame in this instrument will be replaced by an adapter block. It provides more workspace for surgical tools by securely and precisely holding the mouse or newborn rat. The stereotaxic instruments come with three dimensions, a left-handed manipulator arm, a mouse nose clip, mouse 18° and 45° ear bars, and a conventional probe holder. Also accessible are other subassemblies like dual arm, digital, etc.

Key Features:

For mice, a specialized solid base (255 x 255 mm) that can be fixed more rapidly.
Replace the U-frame for a larger, more dependable and cost-effective working area.
A special UP sign to guard against improper operation.
More accurate and stable functioning thanks to the double-lead screw construction.
The polyoxymethylene resin used to make the ear bar has four distinct fixed points with a resolution of 1mm for scales.

Technical Parameters

Base plate dimensions are 255mm by 255mm.
Unique and lightweight ear bands made of polyoxymethlene resin.
The palate clip's height modification range is 0 to 20 millimeters.
The ear bars' height modification range is 20mm (0–+20mm).
Scales on ear bars with laser engraving (1mm resolution).
Working distance in three dimensions is 80 mm, and alignment accuracy is 0.1 mm.
Vertical movement and locking at any angle of 180 degrees.
Rotate 360 degrees in the horizontal path and lock at any angle.
Screws with two leads guarantee steady, precise, and fluid manipulation.
Variable temperatures allow for the maintenance of accuracy and adaptability.
The knob's distinctive UP mark, engraved in the anti-clockwise direction, stops misuse.
To guarantee precise operation at any angle, the vertical lock and fixation knob are separated.
Replace the U-frame for a larger, more dependable and cost-effective working area.
Scales with laser engraving make reading them easy.
More stability is provided by ear bar fixed plate pressing rather than clamping.
The tools have attachment points for a drill, micro camera, and syringe pump.

Model Information

Category	Model	Product Description	Remark
Stereotaxic host (without accessories)	68805	Portable Mouse Stereotaxic Instrument, SGL M	Standard configuration, non-digital model (accuracy is 100μm), including 68863S base, 68401 3-axis manipulator-left, without nose bar, ear bars, holder and mask.
	68806	Portable Mouse Stereotaxic Instrument, Dual M	Standard configuration, non-digital model (accuracy is 100μm), including 68863D base, 68401 3-axis manipulator-left, 68402 3-axis manipulator-right, without nose bar, ear bars, holder and mask.
	68807	Portable Mouse Stereotaxic Instrument, SGL M, Digital	Standard configuration, digital model (accuracy is 10μm), including 68863S base, 68409 3-axis digital manipulator-left, without nose bar, ear bars, holder and mask.
	68808	Portable Mouse Stereotaxic Instrument, Dual M, Digital	Standard configuration, digital model (accuracy is 10μm), including 68863D base, 68409 3-axis digital manipulator-left, 68410 3-axis digital manipulatorright, without nose bar, ear bars, holder and mask.
Required accessories (optional)*	68033	Nose Bar for 68030 Mouse Adaptor	Optional, the cross-sectional size of the nose bar is 5* 5mm.
	68313	45°Ear Bars for 68030 Mouse Adaptor	Optional, including two tips of 45° and rubber, the cross-sectional size of the ear bars is 5*5mm.
	68034	18°Ear Bars for 68030 Mouse Adaptor	Optional, including two tips of 18° and serrated, the cross-sectional size of the ear bars is 5*5mm.
	68201	Standard Probe Holder-Corner, clamping range: 0.3-1.5mm.
	68217	Cannula Holder, clamping diameter: 3.5mm.	The clamping part is made of plastic.
	68205	Cannula Holder, clamping diameter: 3.5mm.	The clamping part is made of metal.
	68214	Ceramic Ferrule Holder, clamping diameter: 1.25mm.
	68215	Ceramic Ferrule Holder, clamping diameter: 2.5mm.
	68206	General Probe Holder, clamping range: 3-12mm.
	68218	Syringe Holder, the syringe barrel clamping range is 6mm-12mm, and the syringe needle clamping range is 0.3mm-1.5mm.
	68605	Microdrill Holder, clamping diameter: 14.5mm.	Suitable for 78001 microdrill.

The instrument was used in these investigations:

Reciprocal connections between cortex and thalamus contribute to retinal axon targeting to dorsal lateral geniculate nucleus.
Diao, Y., Cui, L., Chen, Y., Burbridge, T. J., Han, W., Wirth, B., ... & Zhang, J.
(2018). Cerebral Cortex, 28(4), 1168-1182.
Hypersensitivity of prelimbic cortex neurons contributes to aggravated nociceptive responses in rats with experience of chronic inflammatory pain.
Fan, X. C., Fu, S., Liu, F. Y., Cui, S., Yi, M., & Wan, Y.
(2018). Frontiers in molecular neuroscience, 11, 85.
CDYL suppresses epileptogenesis in mice through repression of axonal Nav1. 6 sodium channel expression.
Liu, Y., Lai, S., Ma, W., Ke, W., Zhang, C., Liu, S., ... & Shu, Y.
(2017). Nature communications, 8(1), 1-17.

You can also visit site of the manufacturer.
