78001 Microdrill

78001 Microdrill

The RWD 78001 Manual Skull Microdrill helps you drill a hole in skull in just a few seconds by hand or by being attached to the skull drill holder of a stereotaxic instrument.

Only a few seconds are needed to drill with the handheld cranial drill. It is straightforward to use and simple to master. It can also thin the skull if it has a flat head.

Opening a hole in the skull is the initial stage in the brain stereotaxic positioning procedure in order to easily implant the injection needle, electrode sleeve, tube microdialysis catheter, and other devices. This opening function is made possible by the mini hand-held cranial drill, which has the option of either holding the hole or fixing it to the cranial drill holder of the brain stereotaxic apparatus. The process is straightforward and simple to master.

The skull must initially be punctured in order to conveniently implant the injection needle, electrode sleeve, and micro-dialysis catheter during the stereotactic placement of the brain. This piercing capability is possible with the micro-hand-held cranium drill. It can be used as a hand-held drill or fixed to the stereotactic instrument's cranial drill holder. Both options are simple to use and simple to master.

Technical Parameters

  1. The velocity can be changed continuously between 0 and 38,000 RPM.
  2. The rotational direction can be reversed.
  3. Manual or foot operation is available for two control modes.
  4. Cranial drill gripper (68605).
  5. The depth is simple to control because it can be fixed to the brain stereotactic locator.
  6. The 0.5-2.3mm range can be chosen based on the needs of the experiment.
  7. A variety of specifications bit (44 mm diameter Φ: length L: 2.3 m).

Model Information

  • 78001 Microdrill (bits not included)
  • 78040 Drill Bits HM1005 0.5mm, Round Tip, pkg of 5
  • 78041 Drill Bits HM1006 0.6mm, Round Tip, pkg of 5
  • 78042 Drill Bits HM1008 0.8mm, Round Tip, pkg of 5
  • 78043 Drill Bits HM1010 1.0mm, Round Tip, pkg of 5
  • 78044 Drill Bits HM1012 1.2mm, Round Tip, pkg of 5
  • 78045 Drill Bits HM1014 1.4mm, Round Tip, pkg of 5
  • 78046 Drill Bits HM1016 1.6mm, Round Tip, pkg of 5
  • 78047 Drill Bits HM1018 1.8mm, Round Tip, pkg of 5
  • 78048 Drill Bits HM1021 2.1mm, Round Tip, pkg of 5
  • 78049 Drill Bits HM1023 2.3mm, Round Tip, pkg of 5

You can also visit site of the manufacturer.

RWD Life Science Inc.
We are a distributor of RWD Life Science Inc. in Estonia, Latvia, Lithuania and Ukraine, Kazahstan and Europe
