Carbon Fiber and Carbon Disk Microelectrodes

With WPI carbon microelectrodes it is possible to detect various oxidizable substances in solutions. They can also be used to record extracellular electrical activity.

Overview
Specifications

Oxidizable compounds in solutions are determined using WPI carbon microelectrodes. The recorded current from these electrodes depends linearly on the concentration of the chemical being measured, such as catecholamines, indolamines, NO, hormones, oxygen,...

These microelectrodes can also be used to record electrical activity outside of cells.

Uncoated carbon microelectrodes
	Diameter	Length
CF10-100	10 µ	100 µ
CF10-250	10 µ	250 µ
CF30-50	30 µ	50 µ
CF30-100	30 µ	100 µ
CF30-1000	30 µ	1000 µ
Nafion-coated carbon microelectrodes (increased sensitivity to catecholamines)
	Diameter	Length
CFN10-50	10 µ	50 µ
CFN10-100	10 µ	100 µ
CFN10-250	10 µ	250 µ
CFN10-500	10 µ	500 µ
CFN30-50	30 µ	50 µ
CFN30-100	30 µ	100 µ
CFN30-250	30 µ	250 µ
CFN30-500	30 µ	500 µ
CFN30-1000	30 µ	1000 µ
